| الدفع نوع: | T/T,D/P,D/A |
| إنكوترم: | FOB,CFR,CIF,EXW,FAS,FCA,DDP,DDU |
| أدني كمية الطلب: | 100 Kilogram |
| نقل: | Ocean,Land,Air,Express |
| ميناء: | Shenzhen,Guangzhou |
الظل:
نموذج: G10 Sheet
علامة تجارية: XYH
Origin: الصين
شهادة: ISO9001
مكان المنشأ: الصين
محيط: ورقة العزل
مواد: الألياف الزجاجية
نطاق التطبيق: جهد منخفض, الجهد العالي
Product Grade: NEMA G10
Material: Epoxy Resin and Fiberglass Cloth
Product Form: Rigid Laminated Sheet
Standard Color: Natural Yellow Green
Surface Finish: Smooth or Matte
Thickness Range: 0.2–100 mm
مقاس معياري: 1020×1220 mm, 1220×2440 mm
Custom Size: Cutting and Custom Sizes Available
Key Properties: High Mechanical Strength and Electrical Insulation
Water Absorption: Low Water Absorption
Machinability: Suitable for CNC Milling, Drilling and Cutting
Typical Application: Electrical Insulation and Mechanical Components
Application Parts: Insulation Plates, Spacers, Jigs and Fixtures
Flame Retardancy: Non-Flame-Retardant Grade
Processing Service: Cutting, Drilling, Milling and Custom Machining
| بيع الوحدات | : | Kilogram |
| نوع الحزمة | : | البليت |
The file is encrypted. Please fill in the following information to continue accessing it
| Property | Typical Information |
| Product grade | NEMA G10 |
| Material construction | Woven fiberglass cloth with epoxy resin |
| Product form | Rigid laminated sheet |
| Standard appearance | Natural yellow-green to light green |
| Flame resistance | Non-flame-retardant grade |
| Typical working temperature | Up to 130°C, subject to grade and actual operating conditions |
| Typical glass transition temperature | 110–130°C; typical value, subject to batch COA |
| Main properties | Electrical insulation, high strength, rigidity and dimensional stability |
| Available processing | Cutting, CNC milling, drilling, tapping, routing and custom machining |
| Supply format | Full sheets, cut-to-size pieces or machined parts |
| Selection Point | G10 | FR4 |
| Base construction | Epoxy resin with fiberglass cloth | Epoxy resin with fiberglass cloth |
| Flame resistance | Not designed as a flame-retardant grade | Flame-retardant grade; any specific rating must be verified by the relevant report |
| Typical reason to buy | Mechanical strength and electrical insulation without a flame-retardant requirement | Electrical or structural insulation where flame resistance is specified |
| Before ordering | Confirm temperature, voltage, thickness and machining needs | Confirm flame rating, grade, supporting documents and end-use requirements |
